Dynamic storing with Kardex VLM Box
The Kardex VLM Box is extremely lightweight and completely flexible in terms of height, width, and depth, making it possible to create more than 300 different storage compartments in just one box.
In addition to being tidier, the box’s space-saving sorting concept increases storage capacity by up to 20 percent – an invaluable benefit.
The VLM Box can do even more: Thanks to its modular design, it can be adapted in an instant to cope with changes to the inventory. Straightforward handling of the boxes makes it easy for the customer to save space immediately and benefit from the many clear advantages the boxes have to offer.
Why Kardex VLM Box?
- Maximum flexibility due to the individual design with over 300 storage compartments
- Simple scalability due to the expandable box system
- Fewer picking errors due to the items being arranged in a specific way
- Secure storage due to the tailored space for each item

Made for Kardex Remstar VLM trays
The VLM BOX system can be used for 610, 813 and 864 mm deep trays in a Kardex Remstar Vertical Lift System .
- 610 mm depth: Use the Kardex VLM Box 800 front 600 to get the depth of approx. 600 mm.
- 813 mm depth: Use the Kardex Box 800 front 800 to get the depth of approx. 800 mm
- 864 mm depth: Use the Kardex VLM Box 850 front 850 to get the depth of approx. 850 mm
Start saving space with a StartKit!
- Kick-start your space saving
- Easy and risk-free choice
A StartKit gives you the versatility of the Kardex VLM Box system and provides you with a wide range of opportunities while being easy to extend. Choose between our different StartKit options to get off to flying start with Kardex VLM Box. For instance, the StartKit 1 Big consists of 100 core boxes that can provide up to over 2 000 locations in 33 different sizes. Read more about the available StartKits by downloading the product sheet.
Technical data
We have 2 different Kardex VLM Boxes to offer.
Kardex VLM Box 800 with out side dimension appr. 600x800x50 and our new product Kardex VLM Box 850 with outside dimensions appr. 600x850x50.
For both Kardex VLM Boxes you can fill 2, 3, 4, 5, or 6 bases to fill up your Kardex Vertical lift systems different tray types.
For our Kardex VLM Box 800 we use transparent dividers, for our new Kardex VLM Box 850 we use same type of environment friendly Silver fir blue polypropene as we use for our base and frame. Both transparent and silver fir blue dividers are placed in both directions so you can create the locations sizes to match you specific needs.
The Kardex Box Base has always the same height but adjusted to 50, 100, 150, 200 mm and so on by using Kardex VLM Box Frame with it´s unique easy click system easy to assembly.
Kardex VLM Box and frames are both in Silver Fir Blue. Color variations may occur from batch to batch. Returns based on color variations are not accepted.
PRODUCT |
|
SAP ART. NO |
|
MASS (G) |
|
DIMENSIONS (MM) |
|
COLOR |
Kardex VLM Box 800 Base |
|
7051162 |
|
1322 |
|
790x598x48 |
|
Silver Fir Blue |
Kardex VLM Box 800 Frame |
|
7051170 |
|
363 |
|
784x592x50 |
|
Silver Fir Blue |
Kardex VLM Box 800 Divider 50x600 |
|
7051188 |
|
66 |
|
585x39 |
|
Transparent |
Kardex VLM Box 800 Divider 50x800 |
|
7051196 |
|
88 |
|
777x39 |
|
Transparent |
Kardex VLM Box 800 Divider 100x600 |
|
7051204 |
|
156 |
|
585x89 |
|
Transparent |
Kardex VLM Box 800 Divider 100x800 |
|
7051212 |
|
211 |
|
777x89 |
|
Transparent |
Kardex VLM Box 800 Divider 150x600 |
|
7051220 |
|
244 |
|
585x139 |
|
Transparent |
Kardex VLM Box 800 Divider 150x800 |
|
7051238 |
|
323 |
|
777x139 |
|
Transparent |
Kardex VLM Box 800 Divider 200x600 |
|
7051246 |
|
319 |
|
585x189 |
|
Transparent |
Kardex VLM Box 800 Divider 200x800
|
|
7051253 |
|
431 |
|
777x189 |
|
Transparent |
|
|
|
|
|
|
|
|
|
Kardex VLM Box Spacer Base |
|
7135114
|
|
400 |
|
600x100 |
|
Silver Fir Blue |
Kardex VLM Box Spacer Divider |
|
7135122 |
|
120 |
|
58x85
|
|
Silver Fir Blue |
Label holder single |
|
7051311 |
|
6 |
|
92x30 |
|
Transparent |
Label holder double |
|
7051329 |
|
10 |
|
92x30+30 |
|
Transparent |
PRODUCT |
|
|
|
SAP ART. NO |
|
MASS (G) |
|
DIMENSIONS (MM) |
|
COLOR |
Kardex VLM Box 850 Base |
|
|
|
12333064 |
|
1650 |
|
598,8 (+- 1,5) x 850,0 (+-2,0) x 53,0 (+-0,15) |
|
Silver Fir Blue |
Kardex VLM Box 850 Frame |
|
|
|
12333065 |
|
490 |
|
598,8 (+- 1,5) x 850,0 (+-2,0) x 50,0 (+-0,15) |
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 50x600 |
|
|
|
12333068 |
|
70 |
|
44,7 (+-0,15) x 585,0 (+-1,5) |
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 50x850 |
|
|
|
12333072 |
|
100 |
|
44,7 (+-0,15) x 836,3 (+-2,0) |
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 100x600 |
|
|
|
12333069 |
|
140 |
|
94,7 (+-0,15) x 585,0 (+-1,5)
|
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 100x850 |
|
|
|
12333073 |
|
200 |
|
94,7 (+-0,15) x 836,3 (+-2,0)
|
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 150x600 |
|
|
|
12333070 |
|
220 |
|
144,7 (+-0,15) x 585,0 (+-1,5) |
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 150x850 |
|
|
|
12333074 |
|
320 |
|
144,7 (+-0,15) x 836,3 (+-2,0) |
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 200x600 |
|
|
|
12333071 |
|
310 |
|
194,7 (+-0,15) x 585,0 (+-1,5) |
|
Silver Fir Blue |
Kardex VLM Box 850 Divider 200x850
|
|
|
|
12333075 |
|
430 |
|
194,7 (+-0,15) x 836,3 (+-2,0) |
|
Silver Fir Blue |
|
|
|
|
|
|
|
|
|
|
|
Kardex VLM/VBM Box Labelholder Single |
|
|
|
7051311
|
|
6 |
|
92x30 |
|
Transparent |
Kardex VLM/VBM Box Labelholder Double |
|
|
|
7051329 |
|
10 |
|
92x30+30
|
|
Transparent |
Download the Kardex VLM Box 800 / Kardex VLM Box 850 product folder to find out more about this modular system or visit the Kardex Remstar website.

For sales enquiries please contact your local Kardex Remstar office or let us make the introduction by filling out our contact form
